Depolymerization machine

The artificial graphite depolymerizer is a key equipment for the preparation of negative electrode materials for lithium batteries. It is mainly used to break graphite aggregates, reduce particle aspect ratio, and improve tap density, thereby optimizing the fast charging performance and cycle life of negative electrode materials. It achieves spheroidization of graphite particles through high-speed mechanical force, solving the problems of multiple particle edges, poor flowability, and low batch consistency in traditional processes.

Quote Now

Product Highlights

Breakthrough in sphericity rate

Achieving multiple cycles of material flow reversal, achieving a compacted density of 1.2g/ml and a 15% increase in charge and discharge efficiency.

Energy consumption optimization

Multi force field collaborative design reduces energy consumption per ton of material to ≤ 25kW · h, saving 30% energy.

Zero metal pollution

The contact surface is made of 316L stainless steel or ceramic lining plate to prevent the migration of iron and zinc ions and meet battery grade purity standards.

Anti blocking and anti residue

Hydraulic flipping structure+self-cleaning scraper, residual rate<0.1%, supports 120 hours of continuous operation.

Predictive maintenance

Bearing temperature vibration sensor warning failure, accuracy>95%, reducing unexpected shutdowns.

Product Parameters

Processing power (kg/h)	Finished particle size (μm)	Spindle speed(r/min)	Power configuration	Gradual wheel speed(r/min)
120~500	D50=5~300	3800~14000	Customized according to the system	60~2000

Swipe left and right to view the complete table
